ceiling fan making machine spindle thread making machine TB-40S

FOB Reference Price:Get Latest Price
US $15,160-16,160 / Sets | 1 Set/Sets it is for ceiling fan spindle making machine (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Application:
connectors, bicycles, auto parts, pipe fittings industry
Production Capacity:
4-25 pcs/min
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
TOBEST
Model Number:
TB-40S
Voltage:
3phase 380V 50Hz
Power(W):
5512W
Dimension(L*W*H):
1570*1740*1340mm
Weight:
2800(KG)
Certification:
ISO 9001-2008, CE
Warranty:
1 year for ceiling fan spindle making machine
After-sales Service Provided:
Engineers available to service machinery overseas
Name:
ceiling fan making machine spindle thread making machine TB-40S
Color:
Green(or according to your need)
Outside diameter of rolling die:
135mm-215mm
Inside diameter of rolling die:
75mm
Thickness of rolling die:
120mm
Work piece diameter:
5-80/mm
Range of pitch rolled:
1.0-5.0P
Length of thread rolled:
In feed and thru feed
Bearing brand:
NSK,UBC
The highest feed pressure:
16T
SupplyAbility
SupplyAbility:
80 Unit/Units per Month it is for ceiling fan spindle making machine
Packaging & Delivery
Packaging Details
1. ceiling fan spindle making machine is packed in wooden case
2. neutral package can be accepted
Port
ShenZhen
Lead Time :
15-35 days

ceiling fan making machine spindle thread making machine TB-40S


Features:
1.Spindle with double row needle roller bearings and cylindrical roller bearings.
2.Transmission system using multi-polar spindle gear box, to achieve smooth transmission, shifting easily.
3.Hydraulic system with modular valves, small footprint, beautiful appearance, stable performance, and ease of use and maintenance.
4.High precision, stability and high durability.
5.According to customers‘ requirement, automatic feeding device can be added.
Technical Parameter of TOBEST TB-40S
Work piece diameterφ5-φ80/mm
Range of pitch rolled1.0-5.0P
Length of thread rolledIn feed and thru feed
Spindle speed16/25/40/63(r/min)
Outside diameter of rolling dieφ135mm-φ215mm
Inside diameter of rolling dieφ75mm
Thickness of rolling die120mm
Min.Distance between die spindles130mm
Max.Distance between die spindles260mm
Output(pcs/min)4-20 pcs/min
Machine motor7.5HP(5512W)
Hydraulic motor2HP
Max.feed pressure16T

Products display:

Package:
Our company:

it is ceiling fan spindle making machine for sale



FAQ:

1 Payment

What are the terms of payments you offer?

Payment of the goods should be sent in USD or RMB on the basis of goods Values. We accept payment of T/T, PayPal and cash only

2 Shipment

How long will it take to deliver goods?

We will deliver the goods within 10 days for spare parts, other goods maybe take a little more times to test and prepare, we will deliver the goods within the deadline which both parties agreed.

What kind of packaging you offer?

We will pack the goods well with exporting packages to make sure all goods in a good condition during storage and delivery.

What kind of transportation methods you offer?

We always transport by sea for the goods with large quantity, and we will confirm freight with buyers' prior delivery.

How about the insurance during transportation? How to deal with the responsibility?

Buyers should take the full responsibility for shortage of goods if the goods are checked by any custom during transportation. During transportation, if goods are missed because of having been detained by custom in China, all loss thus occurred should be borne by us; if missing or detained of goods are occurred in other country except China, all loss should be borne by buyers

What Locations can you ship to?

We can send the goods to the whole world if the shipping way can deliver it.

3 Others

What kind of problem will happen usually?

Some goods will be out of stock and cannot offer, because it cannot meet the quality request or really out of stock. Anyway we will contact the client to confirm well before shipping.

4 Warrantee & After-sale service:

1. all of our products give 1 year warranty

2. man-made destroy will be exception

3. after the warrantee time, if we still in cooperation, we will give cost repairment if still can repair.

4. for reducing the cost of our customers, we can supply the materials or tech support to them, help them fix the problems in their hands

5. We will pay the delivery charge from us to customers if the repair, return or replacement cases happen

Contact:

1.our working time: 8:00am~5:30pm

2. all the inquiries will be replied within 24hours, So please feel free to send us your inquiry.

3. when our trade manager is off line, please feel free to leave a message, and tell us the products you need, our model number, and your E-mail address, we will reply to you within 24hours.
